• Chawanvuth Termtanun Department of Orthopedics, Phramongkutklao Hospital, Bangkok
  • Thanainit Chotanaphuti Department of Orthopedics, Phramongkutklao Hospital, Bangkok
  • Saradech Khuangsirikul Department of Orthopedics, Phramongkutklao Hospital, Bangkok
  • Danai Heebtamai Department of Orthopedics, Phramongkutklao Hospital, Bangkok



Ultrasonogram, Radiographic staging, Osteoarthritic knee, Synovitis, Synovial hypertrophy


Background: Treatment of primary osteoarthritic (OA) knee has changed in recent decades with a greater focus on synovitis as one cause of cartilage destruction and degeneration. Ultrasonography (US), a noninvasive, low cost and convenient procedure may be used for early detection and monitoring synovitis in primary OA knee. Somehow, the lack of data on the prevalence of synovial hypertrophy (SH) and its correlation to disease progression has precluded the use of US in clinical practice.

Objective: The study aimed to determine the prevalence of SH at each stage of the disease and its correlation to structural damage.

Methods: In all, 214 knees among 127 cases diagnosed as having primary OA knee were examined using US. The midline scanning technique of US was performed and synovial thickness at the suprapatellar pouch was observed. All knees were categorized according to the Kellgren-Lawrence radiographic staging (KL). The prevalence of SH in each KL with 2, 2.5 and 3 mm cutoff level were calculated. The correlation between synovial thickness and KL was also analyzed.

Results: The prevalence of SH with 2 mm cutoff level in KL I-IV was 38.8, 70.8, 66.6 and 91.1%, respectively. The prevalence of SH with 2.5 mm cutoff level in KL I-IV was 5.5, 37.5, 35.4 and 74.2%, respectively. The prevalence of SH with 3 mm cutoff level in KL I-IV was 0, 29.1, 20.8 and 56.4%, respectively. The overall prevalence with 2, 2.5 and 3 mm cut-off level was 72.2, 50.9 and 37.1%, respectively. Synovial thickness, measured in millimeters, correlated well with KL (p<0.01). The correlation of synovial thickness between each KL was also statistically significant (p<0.05) except those between KL II and KL III (p=0.98).

Conclusion: Synovial thickness at the suprapatellar pouch detected with midline scanning US reflected the degree of synovitis which correlated well with structural damage and could be used to monitor disease progression in primary OA knee.


Metrics Loading ...


Wang Y, Teichtahl AJ, Abram F, Hussain SM, Pelletier JP, Cicuttini FM, Martel-Pelletier J. Knee pain as a predictor of structural progression over 4 years: data from the Osteoarthritis Initiative, a prospective cohort study. Arthritis Res Ther 2018; 20: 250. DOI:

Mathiessen A, Conaghan PG, Synovitis in osteoarthritis: current understanding with therapeutic implications. Arthritis Res Ther 2017; 19: 18. DOI:

Felson DT, Niu J, Neogi T, Goggins J, Nevitt MC, Roemer F et al. Synovitis and the risk of knee osteoarthritis: the most study. Osteoarthritis Cartilage 2016; 24: 458-64. DOI:

Chu CR, Millis MB, Olson SA. Osteoarthritis: From palliation to prevention: AOA critical issues. J Bone Joint Surg Am 2014; 96:e130. DOI:

Heidari B. Knee osteoarthritis prevalence, risk factors, pathogenesis and features: Part I. Caspian J Intern Med 2011; 2:205-12.

Roos EM, Arden NK. Strategies for the prevention of knee osteoarthritis. Nat Rev Rheumatol 2016; 12: 92-101. DOI:

Berenbaum F. Osteoarthritis as an inflammatory disease (osteoarthritis is not osteoarthrosis!). Osteoarthr Cartil 2013; 21:16-21. DOI:

Daghestani HN, Kraus VB. Inflammatory biomarkers in osteoarthritis. Osteoarthritis Cartil 2015; 23: 1890-6. DOI:

Malfait AM. Osteoarthritis year in review 2015: Biology. Osteoarthr Cartil 2016 ; 24: 21-6. DOI:

Orlowsky EW, Kraus VB. The role of innate immunity in osteoarthritis: When our first line of defense goes on the offensive. J Rheumatol 2015; 42: 363-71. DOI:

Scanzello CR, Goldring SR. The role of synovitis in osteoarthritis pathogenesis. Bone 2012; 51: 249- 57. DOI:

Sellam J, Berenbaum F. Is osteoarthritis a metabolic disease? Jt Bone Spine 2013; 80: 568-73. DOI:

Varady NH, Grodzinsky AJ. Osteoarthritis year in review 2015: Mechanics. Osteoarthr Cartil 2016; 24: 27-35. DOI:

Iagnocco A. Imaging the joint in osteoarthritis: a place for ultrasound? Best Pract Res Clin Rheumatol 2010; 24: 27-38. DOI:

Sarmanova A, Hall M, Moses J, Doherty M, Zhang W. Synovial changes detected by ultrasound in people with knee osteoarthritis - a meta-analysis of observational studies. Osteoarthr Cartil 2016; 24: 1376-83. DOI:

D’Agostino MA, Conaghan P, Le Bars M, Baron G, Grassi W, Martin-Mola E, et al. EULAR report on the use of ultrasonography in painful knee osteoarthritis. Part 1: prevalence of inflammation in osteoarthritis. Ann Rheum Dis 2005; 64: 1703-9. DOI:

Mermerci BB, Garip Y, Uysal RS, Dogruel H, Karabulut E, Ozoran K, et al. Clinic and ultrasound findings related to pain in patients with knee osteoarthritis. Clin Rheumatol 2011; 30: 1055-62. DOI:

Iagnocco A, Meenagh G, Riente L, Filippucci E, Delle Sedie A, Scire CA, et al. Ultrasound imaging for the rheumatologist XXIX. Sonographic assessment of the knee in patients with osteoarthritis. Clin Exp Rheumatol 2010; 28: 643-6.

Hall M, Doherty S, Courtney P, Latief K, Zhang W, Doherty M. Synovial pathology detected on ultrasound correlates with the severity of radiographic knee osteoarthritis more than with symptoms. Osteoarthr Cartil 2014; 22: 1627e33 DOI:

Karim Z, Wakefield RJ, Quinn M, Conaghan PG, Brown AK, Veale DJ, et al. Validation and reproducibility of ultrasonography in the detection of synovitis in the knee: a comparison with arthroscopy and clinical examination. Arthritis Rheum 2004; 50: 387-94. DOI:

Iagnocco A, Perricone C, Scirocco C, Ceccarelli F, Mariagrazia M, Gattamelata A, et al. The interobserver reliability of ultrasound in knee osteoarthritis. Rheumatology (Oxford). 2012; 51: 2013-9. DOI:

Altman R, Asch E, Bloch D. Development of criteria for the classification and reporting of osteoarthritis: Classification of osteoarthritis of the knee. Arthritis Rheum 1986; 29: 1039-49. DOI:

Alves TI, Girish G, Kalume Brigido M, Jacobson JA, US of the Knee: Scanning Techniques, Pitfalls, and Pathologic Conditions. Radiographics. 2016 ;36: 1759-1775. DOI:

Gandikota G, Tun M. Ultrasound of the hip in rheumatology. Indian J Rheumatol 2018; 13: 29-35.

Kohn MD, Sassoon AA, Fernando ND. Classifications in Brief: Kellgren-Lawrence Classification of Osteoarthritis. Clin Orthop Relat Res 2016 ; 474: 1886-93. DOI:




How to Cite

Termtanun C, Chotanaphuti T, Khuangsirikul S, Heebtamai D. SYNOVIAL HYPERTROPHY DETECTED USING ULTRASONOGRAM IN PRIMARY OSTEOARTHRITIC KNEES: PREVALENCE AND CORRELATIONWITH RADIOGRAPHIC STAGING. J Southeast Asian Med Res [Internet]. 2020 Jun. 23 [cited 2024 Feb. 21];4(1):33-40. Available from:
